Assignee Vs Technology

#Please note that above data is based on one member per family.

Insights:

• Only Lessmueller has an asset which talks about using interferometric measurement to determine inclination profile (For example, DE102016001661B3).
• Precitech is aggressive to file patents related to the use of interferometric measurement to determine distance and material thickness profile.
• Lessmueller patents have more filings related to adjusting the position of the laser beam based on measurement profiles where as Precitec filings are more focused on adjusting speed, laser power and intensity control.

Executive Summary

#Please note that Applicants & Geographical analysis graphs are based on all published family members

#Please note that above Category Wise Pie-charts are based on one member per family.

#A representative family member may fall under multiple sub level categories.

Executive Summary (PRECITEC)

#Please note that Filing trends & Legal status overview graphs are based on all published family members.

#Please note that the data for the current year (2024) is not complete.

Insights:

• Precitec filed maximum number of patent applications in 2018 and 2019.
• Patents filed in 2019 (for e.g.  US11079218B2 & US11623299B2) focused more on adjusting a machining speed, a laser power, a laser focus, and/or operating parameters of the laser device based on topography measurement.
• Currently 320 patents/patent applications of Precitec are ‘Alive’ & 60 patents/patent applications are ‘Dead’.

Taxonomy (Low Level)

#Please note that above data is based on one member per family.

#A representative family member may fall under multiple sub level categories.

Bibliographic Trends PRECITEC

#Please note that Grant year and Publication Year graphs are based on all published family members.

#Please note that the data for the current year (2024) is not complete.

Insights:

• Maximum number of Precitec patents were granted in 2021 and 2022.
• Patents granted in 2021 and 2023 (for e.g.  US11079218B2 & US11623299B2) were focused more on adjusting machining speed, laser power, laser focus, and/or operating parameters of the laser device based on topography measurement. These assets are primarily disclosing about measuring the topography and/or depth of the keyhole of a spot around the workpiece (i.e. weld seam) by using interferometric measurement techniques and further the measurement values are used for error detection and/or control of one or more process input variables, where the process input variables may include, for example, a machining speed, a laser power, a laser focus, and/or operating parameters of the laser device.

Related Resources:

White Space Analysis - Interferometric Measurements: Overview

White Space Analysis- Interferometric Measurements Product Details

Filing Year Vs Technology – PRECITEC

Patent Focus Vs Filing Year

#Please note that  this graph is based on all published family members.

# A patent might fall in multiple categories..

#Please note that the data for the current year (2024) is not complete.

Insights:

• In recent years, large number of filings are focused on measuring Depth/Distance profile.
• Only two patent applications filed in 2020 and 2021 talked about intensity control of the laser beam based on measurement profiles. (i.e. DE102020104484A1)
• Filings related to measuring Height profile started in 2013.
• Most of the filings disclosing about adjusting/controlling position of the laser beam based on measurement profiles followed by controlling speed of the laser beam started in 2013 (for e.g. US20240149456A1, US11079218B2)

Executive Summary (Lessmueller)

#Please note that Filing trends & Legal status overview graphs are based on all published family members.

Insights:

• Lessmueller filed maximum number of patent applications in 2015 and 2023.
• Patents filed in 2023 (for e.g. US20240149456A1 & US20240149374A1) focused more on position control of the LASER BEAM. These patents primarily disclosed use of an OCT measurement sensor to measure several positions in an edge of the workpiece.
• Currently 29 patents/patent applications of Lessmueller are ‘Alive’ & 1 patents/patent applications is ‘Dead’.

Bibliographic Trends LESSMUELLER

#Please note that Grant year and Publication Year graphs are based on all published family members.

#Please note that the data for the current year (2024) is not complete.

Insights:

• Maximum number of Lessmueller patents were granted in 2017.
• Recently published applications in 2024 (for examples US20240149456A1 , US20240149374A1) are focused more on position control of the LASER BEAM. . These patents primarily disclosed about using an OCT measurement sensor for measuring several positions in a edge of the workpiece and performing the positioning of the machining head as well as the positioning of the sample beam in accordance with the position information.

White Space Analysis

Measuring Profile vs Feedback for Precitec

Strength:

Precitec has aggressively filed in adjusting position of the laser beam considering different measuring profiles.

Weakness:

Precitec has very few assets considering height and position profile for adjusting the laser beam.

Opportunity:

Use of geometry profile for adjusting the laser power of a working beam can be considered as a good space for future filings.

Threat:

Precitec has some seminal patents which talk about the use of height and geometry profile measurements for providing feedback to the working beam.

Measuring Profile vs Feedback for Lessmueller

Strength:

Lessmueller has majority of their filings talking about adjusting the position of the laser beam and making use of depth and height profile.

Weakness:

Lessmueller has few fillings which talks about providing specific feedback to the working beam.

Opportunity:

Use of position and inclination profiles for adjusting the laser power of a working beam can be considered as a good space for future filings.

Threat:

Lessmueller has some seminal patents which talk about the use of measured position, geometry and inclination profiles for providing feedback to a working beam.
